CTW CAM-16 Odd-form Inserter

CTW CAM-16 is a compact high-speed odd-form inserter in CAM series. It realizes 6,000 CPH insertion capacity with a reduced machine body, designed for manufacturers with limited workshop space. CAM-16 can handle diverse through-hole odd-form components for PCBA DIP assembly. The optimized mechanical structure guarantees stable running in long-hour mass production. It can work with multiple types of component feeders, and is widely adopted in industrial control boards, lighting electronics and small power unit production lines.

Key Features

1. Insertion speed up to 6,000 CPH with compact body design

2. Small footprint, saves valuable factory floor space

3. High precision insertion mechanism, reduces bent pin defects

4. Quick recipe switching for different component types

5. Built-in fault diagnosis, convenient maintenance

6. Supports multiple feeding modes: stick, tray, bulk

7. Smooth PCB conveyor, compatible with inline DIP production

Technical Specification
